Technical data

Li-Ion Battery :
Working time at optimal speed (45m/min)*:
Working time at maximum speed* :
Range* :
Static thrust :
Maximum speed :
1500 Wh / 2300 Wh
> 405min. / > 620min.
> 140min. / > 220min.
> 18 km / 30 km
> 340N
> 1,6 m/s

* Applicable in terms of a diver in a twinset 2x12, in a dry suit, in fresh water. Range tested for optimum speed
Li-Ion Battery :
Nominal battery voltage :
Maximum battery voltage (after charging) :
Minimum battery voltage (after charging) :
Average time of charging 75% :
Average time of charging 90% :
Average time of charging 100% :
Charger operating voltage :
1500 Wh / 2300 Wh
32,4V / 32,4V
37,8V / 37,8V
26,0V / 26,0V
210min. / 320min.
250min. / 370min.
350min. / 580min.
180-250V , 50-60Hz AC, 900 W
Length :
Width :
Height :
Housing diameter :
Weight without battery :
Weight with fresh water battery and ballast (fresh water):
800 mm
360 mm
410 mm
208 mm
12,0 kg
23,2kg
Maximum operational depth :
Maximum tested depth :
Correct bouyancy (with adjusted ballast) :
Scooter operating temperature :
Scooter storage temperature :
Temperature whilst charging :
200m
300m
neutral
-15 / +50⁰C
-20 / +50⁰C
10 / +40⁰C
Set includes:
Battery dedicated to scooter GHOST standard 1500 Wh; long 2300 Wh
Charger 400Wh 9S LiIon dedicated to FUTURE I GHOST scooters
POM transport bracket fi 208
Universal sports camera mount, attached to the control module
Internal scooter ballast – basic module – for all SEACRAFT models
Trimming weight 62g – 3 additional pieces
Trimming weight 182g – 3 additional pieces
Scooter harness 1,8m with carabiners and two adjustment plates
Spare parts set for GHOST – set of seals and grease for seals
Service tools
RETAIL PRICE: GHOST BX 1500 Wh:
7500 EUR netto (taxes excluded)
RETAIL PRICE: GHOST BX 2300 Wh:
8500 EUR netto (taxes excluded)

Discover Seacraft

YOUR RELIABLE DIVING PARTNER

The Seacraft DPV uses modern technological solutions and the best construction materials to appeal to the most demanding divers. The motor is lightweight (16 kg with battery), operates when completely submerged, uses a high-performance drive unit that provides prolonged dive time at a high pulling force, provides constant monitoring of operating parameters via an OLED graphic display computer, and recharges the scooter, all using an ergonomic self-contained control system. These features are just a few of the many innovative solutions that are used in the Seacraft underwater scooter.

SEACRAFT – MADE TO EXPLORE

SEACRAFT – MADE TO EXPLORE



620
minutes
at nominal speed

Expanding underwater horizons

The patented immersed motor is more durable than traditional solutions and effectively eliminates the risk of overheating and flooding of the scooter. The motor, combined with other elements of the drive unit, provide high efficiency, longer distances and dive times. The double-sided steering handle mounted on the scooter allows ergonomic two-handed control and a wide range of smooth speed control.

max speed
m/s
1,60

A new dimension of underwater mobility

Seacraft DPV - the first diving scooter in the world, in which the motor runs directly in the water. Specially designed and patented solutions allow the complete elimination of the drive shaft and the need for expensive and unreliable seals used in all other constructions. The extremely high level of efficiency of the device results from innovative technology, which ensures easy access to very high speeds and depths while ensuring safety and ergonomic use.

average
charging time
2,5
hour

Big Blue Exploration

The exceptional parameters of Seacraft DPV allow for increased possibilities, including the ability to travel long distances underwater and extensive battery life, for hours of continuous diving. The scooter uses a modern lithium-ion (Li-Ion) battery built with high current cells supplied by a reputable manufacturer. Depending on the version, the Seacraft underwater scooter battery has 9 group cells with a total voltage of 37,8V (value after charging).
